2016 Yamaha YZF-R1 Racing Kit Manual

Complete Racing Kit Manual for the Yamaha YZF-R1. Production model years 2016.

Racing Kit Manual Contains:
1 Engine Specifcations
2 Kit Parts
2-1 Installing Electrical Parts
1. ECU Set (2CR-8591A-71)
2. Cable Interface (2CR-8533A-70)
3. Wire Harness Set (2CR-F2590-70)
4. Headlight Harness Set (2CR-F4350-70)
5. Repair set (2CR-28130-70, 2KS-28130-70)
6. CCU COMP. (2KS-85800-70)
2-2 Installing Engine Parts
7. Maintenance Set (2CR-MAINT-71)
8. Spark Plug Set (14B-R465B-70)
9. Piston Set (2CR-116A0-71)
10. Connecting Rod Set (2CR-1165B-70)
11. Crankshaft (2CR-11400-71)
12. High-lift Camshafts, Cam Sprocket
13. Valve Spring Set (2CR-A2110-70)
14. Air Funnel Set (2CR-1440B-70)
15. AIS-plug Set (2CR-A4890-70)
16. Screw cap set (2CR-15171-70)
17. Transmission Gear
18. Mission Maintenance Set (2CR-A7000-70)
19. Drive Sprockets
20. Sprocket Nut Set (2CR-A7463-70)
21. Strainer Cover Set (2CR-13400-70)
2-3 Installing Chassis Parts
22. Spring Rear Shock
23. Spring Front Fork
24. Seat Cushion (13S-24713-70)
25. Front Spare Wheel ASS’Y (2CR-25100-70)
26. Rear Spare Wheel ASS’Y (2CR-25300-70)
27. Tube Guide (2CR-26243-70)
3 Tightening Torque List
Tightening the Cylinder Head
Installing the Crankcase
Procedure to tighten the aluminum bolts
Procedure to install the engine
Procedure to install the pivot shaft peripheral parts
4 Headlight Cord Wiring Diagram
5 YZF-R1 Wiring Diagram


Model Specification: Yamaha YZF-R1
Total Pages: 77
Language: English
File Format: PDF
Requirements: Adobe PDF Reader


All pages are printable, so run off what you need & take it with you into the garage or workshop.

After your payment is submitted, The Download Link will appear at the checkout page and it will also be sent to your E-Mail Address.
