This is the COMPLETE Spare Parts Catalog Manual for the Krone Big Pack 890, Big Pack 1270, Big Pack 1290, Big Pack 890 – XC, Big Pack 1270 – XC, Big Pack 1290 – XC Large Square Balers. Designed for the repair shops and individuals when ordering parts for their Krone Large Square Balers. This Manual describes and illustrates assemblies, subassemblies, and detail parts needed for service replacement. it Covers every part of your Krone Large Square Balers inside and out. Tons of pictures and diagrams at your fingertips!
Models Covered:
=========
Krone Big Pack 890 Large Square Baler
Krone Big Pack 1270 Large Square Baler
Krone Big Pack 1290 Large Square Baler
Krone Big Pack 890 – XC Large Square Baler
Krone Big Pack 1270 – XC Large Square Baler
Krone Big Pack 1290 – XC Large Square Baler
Spare Parts Catalog Manual Contains:
=========
Frame / Drawbar
Support jack -SIMOL
Hydraulic support jack
Single axle cpl.
Air pressure brake fitting
Hydraulic brakes
Tandem axle assy ADR
Tandem axle assy
Air pressure brake fitting
Hydraulic locking facility steering axle
Parking brake
Tyres
Feed packer trough / Cam track cpl.
Packer strip / Feed packer strip
Scraper
Clutch housing installed
Packer control
Oscillating feeler
Frame with cutting roller
Cutting mechanism
Cutting mechanism – lift
Pick-up Pu 1910
Pick-up Pu 2310
Pick-up – Drive Pu 1910/Pu 2310
Pick-up – Lift cpl. Pu 1910/Pu 2310
Feed auger installed Pu 1910
Feed auger installed Pu 2310
Feed auger
Roll-type crop guard
Depth wheel
Main gearbox
Flywheel
Flywheel – Brakes
Auxiliary gearbox – knotters/packer
Packer gear cpl.
Chain drive
Angle gear – top/bottem right
Angle gear
Tooth coupling
Lower angle drive
Connecting rod installed
Plunger with Knives
Knotter gear – Teil I
Knotter gear – Teil II
Knotter table
Singel knotter
Knotter shaft – Singel knotter
Control shaft – Singel knotter
Needle yoke assembled – Singel knotter
Twine guide bottem – Singel knotter
Double knotter
Knotter shaft – Double knotter
Top needle/Control shaft- Double knotter
Needle yoke assembled – Double knotter
Needle yoke assembled – MULTI-BALE
Twine guide bottem – Double knotter
Twine guide top – Double knotter
Manual bale size adjusting facility
Electrical bale size adjusting facility
Bale chamber
Yoke
Chute
Roller type ramp – locking mechanism
Last bale ejector
Front guard
Twine box
Twine box flap
Guard – Packer gear
Rear guards / step
Guard pick-up / Tool box
Grease gun with manual lever
Central knotter Lubrication 890
Central knotter Lubrication 1270/1290
Central lubrication
Central lubrication – single axle
Central lubrication – tandem axle
Compressor with accessories
Knotter cleaning – Air pressure contain.
Knotter cleaning – Single knotter
Knotter cleaning – Double knotter
On-board hydraulic – oil reservoir/valve
On-board hydraulic
On-board hydraulic – Yoke
Work hydraulics
Control
Wiring Harness
Lighting
Fire extinguisher
Wheel chock
Friction clutch cpl.
P.T.O shafts
Warning signs
General information labels
=========
Model Specification: Krone Big Pack 890, Big Pack 1270, Big Pack 1290, Big Pack 890 – XC, Big Pack 1270 – XC, Big Pack 1290 – XC Large Square Balers
From machine no.: 561000 – 584000
Language: English
Total Pages: 350
File Format: PDF
Requirements: Adobe PDF Reader
Compatible: All Versions of Windows & Mac, Linux OS, Iphone, Ipad, Android etc…
=========
