This is the COMPLETE Spare Parts Catalog Manual for the Krone Fortima V1500 – RP601-30, Fortima V1800 – RP601-40, Fortima V1500 MC – RP601-31, Fortima V1800 MC – RP601-41 Round Balers. Designed for the repair shops and individuals when ordering parts for their Krone Round Baler. This Manual describes and illustrates assemblies, subassemblies, and detail parts needed for service replacement. it Covers every part of your Krone Round Baler inside and out. Tons of pictures and diagrams at your fingertips!
Models Covered:
=========
Krone Fortima V1500 – RP601-30 Round Baler
Krone Fortima V1800 – RP601-40 Round Baler
Krone Fortima V1500 MC – RP601-31 Round Baler
Krone Fortima V1800 MC – RP601-41 Round Baler
Spare Parts Catalog Manual Contains:
=========
Drawbar
Ball head o-hitch
Safety chain ASAE-89
Support jack
Frame
Twine box
Idling axle
Tandem axle unbraqked – 40 km/h BPW
Brake axle
Brake coupling to brake valve
Brom brake valve to reservoir
Front brake valve to axle
Hydraulic brakes
Tandem axle
Brake coupling to brake valve
Brom brake valve to reservoir
From brake valve to tandem axle
Hydraulic brakes
Auxiliary brake
Hand brake lever
Bowden cable
Service brake
Tyres / Wheel chock
Swivelling device / brake disc / wrapping roll
Brake lever
Parking brake for wrapping roll
Net tying / knife
Twine tying
Magnetic coupling
Twine tying
Mounting parts for net/twine wrap
Rocker
Rubber roller installed
Main gearbox 540 U/min
Spiral roller with stripper bar
Starter roller / Chain drive
Cover plate
Chain drive lh side
Baling floor drive shaft
Tension equipment -front
Tension equipment -back
Deflector axle for balin chain -back
Baling floor
Elevator stop
Pick-up
Mounting parts Pick-up
Roll-type crop guard
Depth wheel cpl.
Guide wheel support
Chain drive rh side
Pick-up drive
Cutting mechanism
Knife
Safety device against foreign bodies
Feed rotor
Rotor reversing prevention
Cross strut with bale ejector
Front guard
Rubber guard
Lateral guard
Rear guard
Hydraulic – pick-up lift
Connection block for pressure accumulato
Rear gate hydraulics
Hydraulic tensioning device
Central lubrication system – grease
Central lubrication system – oil -part 1
Central lubrication system – oil -part 2
Control unit
Cable harness cutting system
Cable harness comfort
Wiring harness – Twine wrapping
Lighting
Auxiliary lighting
SMV sign
Video system
second camera
ISOBUS – Cable
Terminal – Beta II
Terminal – Delta
Terminal CCI 200
Terminal CCI 1200
Video system / CCI 1200
Tractor retrofitting
Protecting cup
Pto drive shaft
Warning signs
General information labels
Document box
=========
