This is the COMPLETE Spare Parts Catalog Manual for the Krone KW 9.02/8T, KW 11.02/10T, KW 13.02/12T, KW 15.02/14T Rotary Tedder. Designed for the repair shops and individuals when ordering parts for their Krone KW 9.02/8T, KW 11.02/10T, KW 13.02/12T, KW 15.02/14T Rotary Tedder. This Manual describes and illustrates assemblies, subassemblies, and detail parts needed for service replacement. it Covers every part of your Krone KW 9.02/8T, KW 11.02/10T, KW 13.02/12T, KW 15.02/14T Rotary Tedder inside and out. Tons of pictures and diagrams at your fingertips!
Models Covered:
=========
Krone KW 9.02/8T Rotary Tedder
Krone KW 11.02/10T Rotary Tedder
Krone KW 13.02/12T Rotary Tedder
Krone KW 15.02/14T Rotary Tedder
Spare Parts Catalog Manual Contains:
=========
Headstock / Frame / Jack stand
Drive cpl.
T-Gearbox cpl.
Main transmission cpl.
Rotor-Gearbox
Inner support tube- Inter. beam
Intermed. beam – I. beam “b” 11.02-15.02
Intermediate beam “c” 15.02
Outer support tube 9.02 – 15.02
Rotor
Axle
Wheel bracket
Tyres / Guard
Control rod 9.02
Control rod 11.02 – 13.02
Control rod 15.02
Locking mechanism
Guard / Warning panel / Wheel chock
Hydraulics
Lighting
Tine loss prevention equipment
Accessories for East European countries
Main Pto shaft
Main Pto shaft Walterscheid
P.T.O shafts Walterscheid
Warning signs
General information labels
=========
Model Specification: Krone KW 9.02/8T, KW 11.02/10T, KW 13.02/12T, KW 15.02/14T Rotary Tedder
From machine no.: 589000 – 606000
Language: English
Total Pages: 78
File Format: PDF
Requirements: Adobe PDF Reader
Compatible: All Versions of Windows & Mac, Linux OS, Iphone, Ipad, Android etc…
=========
